The SHEEN’s TIV800 Series RTV Thermal Conductive Adhesive are renowned for their distinctive characteristics, which include:
◆ Good thermal conductivity, available in options ranging from 1.0 to 2.0 W/m·K.
◆ High bonding performance.
◆ Good stability, long-term high temperature resistance, and no swelling.
◆ Suitable for automated dispensing equipment operation.
◆ Complies with RoHS, Halogen-Free, and REACH environmental and safety standards.
◆ Good thermal conductivity, available in options ranging from 1.0 to 2.0 W/m·K.
◆ High bonding performance.
◆ Good stability, long-term high temperature resistance, and no swelling.
◆ Suitable for automated dispensing equipment operation.
◆ Complies with RoHS, Halogen-Free, and REACH environmental and safety standards.
【Applications】
◆ Communication Devices
◆ Power Supply Units (PSUs)
◆ LED Modules
◆ Engine Control Units (ECUs)
Properties
| Properties | Unit | TIV800-20 | Test Method |
|---|---|---|---|
| Thermal Conductivity | W/m·K | 2.0 | ASTM D5470 |
| Color | – | White | Visual |
| Main Component | – | Silicone Resin | – |
| Appearance | – | Semi-flowable | – |
| Tack-Free Time (@25℃) | min | 1～5 | – |
| Full Cure Time (@25℃) | h | ≤30 | – |
| Bond Strength | Mpa | ≥1.5 | – |
| Density | g/cm3 | 2.1~2.5 | ASTM D792 |
| Hardness | Shore A | 40～60 | ASTM D2240 |
| Operating Temp. | ℃ | -50~200 | – |
| Dielectric Strength (@AC) | kV/mm | 20 | ASTM D149 |
| Volume Resistivity | Ω·cm | 3.0*1013 | ASTM D257 |
| RoHS | – | PASS | IEC 62321 |
| Halogen | – | PASS | EN14582 |
| REACH | – | PASS | EN14372 |
【Storage & Transportation】
Store in a well-ventilated, cool, and dry place, away from open flames.
This product is non-toxic and should be stored and transported as a non-hazardous material.
【Packaging】
● 30cc ● 300cc
【Shelf Life】
12 months
